TECHNICAL SPECIFICATIONS
Model No. |
PM-A-0600AH-12 |
PM-A-0600AH-24 |
Output power continuous |
600W |
600W |
Instant Surge |
1200W |
1200W |
AC Output Voltage |
220VAC |
220VAC |
Regulation |
±5~10% |
±5~10% |
DC Input Voltage |
10~15V |
20~30V |
Low Battery Alarm |
10.5V±0.5V |
21V±0.8V |
Low Battery Shut-Down |
10V±0.5V |
20V±0.8V |
Input Low Voltage Protection |
Yes |
Yes |
Input High Voltage Protection |
Yes |
Yes |
Reverse Polarity Protection |
Yes |
Yes |
Output Short Circuit Protection |
Yes |
Yes |
Overload |
650W |
650W |
Overload Protection |
Yes |
Yes |
Input/Output Isolated |
Yes |
Yes |
Soft Start |
Yes |
Yes |
AVR Design |
Yes |
Yes |
Auto Temperature Control Fan |
Yes |
Yes |
Remote Control |
No |
No |
Temperature protection |
50°C + 5°C |
50°C + 5°C |
Output frequency |
60Hz + 3% |
60Hz + 3% |
Efficiency |
>85% |
>85% |
No Load Current |
<0.25A> |
<0.25A> |
Dimensions( L x W x H mm) |
250 * 176 * 83 |
250 * 176 * 83 |
Net weight (by Kg/s) |
1.7 |
1.7 |
Accessory( 배터리케이블 길이 1M ) |
Alligator Clip |
Alligator Clip |
Output Waveform |
|
|
